    PART No(E1) 71-1707 to(F) 82-5994
OEM
Part No		 Ref No Description   GBP
UK
PRICE
71-1707
71-2079   side plug rocker box late 500/650 unit 71-2079 Rocker box plug 4
71-2349 - Vent pipe T140V frame to T piece  - 4
71-2662 - 650 engine sprocket late   50
71-2753/6 - Ex pipe set T120 1971,push-over,balanced - 110
71-2889 - bolt rocker box   4
71-2930 - oil pressure switch boot - 4
71-3280/002 - Valve guide Trident +0.002 71-3280-002 valve guide 15

71-3361

V282

TRIDENT VALVE INL 73-ON

 -

15

71-3362

V283

LATE T150/60 EXH. VALVE

 -

16

71-3447

-

T140 OIL PRESS  VALVE


71-3447S - STAINLESS OIL PRESSURE VALVE

49

71-3463

-

DIPSTICK ASSY T140


10.50
71-3476 - TR5T EX SPRING -

71-3542

-

T140 PRIMARY SPROCKET 29T

 -

49

71-3544

-

T140 ALT ROTOR SPACER


3

71-3549

-

750 ROCKER SPINDLE

 -

34

71-3550

W26308

ROCKER FEED PIPE T140


28

71-3552

-

FLYWHEEL/CR-SHAFT BOLT

 -

6

71-3553

-

T140 CTR HD STUD WASHER BRIDGE PIECE


2
71-3556 - TR7 MANIFOLD 71-3556.JPG (5123 bytes)

53

71-3573

-

INLET MANIFOLD GASKET

 -

1
71-3639 - TR5T OIL PIPE -

4
71-3643 - STUD TR5T -

3
- - SLEEVE NUT TR5T -

4

71-3645



TORQUE STAY SLEEVE NUT

 -

15
71-3666   CAMSHAFT TIMING PINION

71-3668

-

T140 IN ROCKER BOX

 T140 Rocker box

99

71-3671

-

T140 TAPPET INP COVER


27

71-3673

-

T140 TAPPET INSP GASKET

 -

1.50
71-3676 W97035 T140 PISTON ASSY STD-JCC,C/W rings,pins circlips 71-3676.JPG (9782 bytes)

80
71-3676/020 71-3687 T140v PISTONS +0.020 JCC c/w Goetze rings
71-3676/40 - T140V PISTONS +40 HARRIS


71-3676/60 - +60 T140V PISTONS-HARRIS T140pistons



71-3681

W94016

T140 COPPER HEAD GASKET

 -

12
71-3681/80 S THICK T140 COPPER HEAD GASKET-80 thou thick -

16

71-3687 19255/020 GENUINE AE UK made HEPOLITE T140 +20 PR

225

71-3687E

W97080

T140V JCC  PISTONS +20

 PR

105
71-3689 E W97081 T140V JCC  PISTONS +40 PR

105
19255/060 +60 Genuine UK made  Hepolite T140 PR

225

71-3700

68-0954

T140 PISTON CIRCLIP

 EACH

0.75

71-3748

99-0062 or WE259A

VALVE COLLET T120/40/50/6


2.25

71-3749

-

WASHER

71-3754

70-3763

OIL FEED PIPE GASKET

 -

0.75

71-3755/8

-

T140 EX PIPES PUSH IN BALANCED

 PR

120

71-3810/11

-

T100/T150 1972 SILENCER BRACKETS

 71-3810-11

24

71-3812/5

T86L/R

T150V EXHAUST PIPES LH AND RH

 -

90

71-3892

-

TIMING POINTER

 -

2

71-3895

-

T140 PRIM C/CASE CAP

 -

6.25

71-3896

-

O-RING

 -

1

71-3910

-

OIL PUMP GASKET

 -

1
71-3974 - T160 VALVE PUSHROD -

10
71-3976 - T160 CAM FOLLOWER -

39

71-3989

-

T140 CRANKCASE DOWEL TOP FRONT

 -

5

71-4000

-

T150 P/ROD TUBE

71-4006 - T140E BARREL

71-4005

-

750 10 STUD CYLINDER BARREL OIL FEED

 T140barrels

245
71-4045 T160 WASHER 7/16 SMALL OD -

0.50

71-4044

-

CR/CASE BREATHER STUB PIPE

 -

3
71-4084 W27154 T160 CABLE PIVOT

71-4097 - CYLINDER HEAD FIN RUBBER PR

4

71-4131

-

TACHO G-BOX END PLUG

6

71-4138

-

TACHO G-BOX T100-160 68on

70-4182 - T160 Rocker feed pipe - 22

71-4159

EMGO

T140 SILENCER

71-4619

-

T140 CYL. HEAD GASKET COMPOSITE

 -

12

71-7008

-

INLET CAMFOLLOWER T140

 -

45

71-7009

T140 PRIMARY CHAINCASE GASKET

 -

5

71-7011

-

TACHO G-BOX T140E

 -

59

71-7013

-

T120/140 OIL FEED PIPE JB

 T140 oil feed

25

71-7016

-

T140 INLET CAMSHAFT


88

71-7017

-

T140 EXHAUST CAMSHAFT


80
71-7017R - RACE EX CAM(SPITFIRE)

120

71-7018

-

AIR INTAKE TUBE CLIP

71-7019

-

T140V AIR INTAKE HOSE


6.25
71-7044 - ROCKER T140E 71-7044.JPG (12233 bytes)

44

71-7045

MD34G

T140 TAPPET ADJUSTER 79ON

 -

5

71-7050

-

LATE T140 EXH ROCKER BOX, fits earlier T140

 T140 Ex rocker box

102

71-7086/STD

-

T140E PISTON KIT STD LOW COMP


71-7086/020

-

T140E PISTONS +20

 -

112

71-7086/040

-

T140E PISTON KIT +40 LOW COMP 7.4-1

 T140lowcomp pistons


71-7086/060 -

71-7103

-

CONNECTOR BAL. PIPE

 -

2
71-7120S - T140D EX ROSE STAINLESS-FOR 2 71-7120Ssa.jpg (5420 bytes)

52

71-7166

-

CONN. SEAL CARB TO A/BOX T140E

 -

3.50

71-7176

-

T140E  OIL FEED JUNCTION BL

 -

25
71-7191A ALLOY PAIR OF 1 PIECE DURAL PUSHROD TUBES T140E DuralpushrodtubesT140E.JPG (12127 bytes)

56

71-7191

-

LATE T140E P/R TUBE




71-7195 TAPPET GUIDE BLOCK -

21

71-7196

-

PUSH ROD TUBE SLEEVE T140E

 -

2

71-7201

B79

INLET VALVE GUIDE T140E


12
71-7201/2 2" OVER SIZE -

12

71-7202

B78

EXH. VALVE GUIDE 80-ON

 -

12
71-7202 - 2" OVER SIZE -

12

71-7203

-

T140E BOTTOM VALVE SPRING CUP

 -

4.25

71-7259

-

PRI/CH. TENS PLUG

 -

5

71-7263

-

T120/40 TIM/COVER GASKET ALL UNIT 650

 -

3
71-7274 - TSS ROCKER BALL PIN -

5
71-7287 - TSS THACKERY WASHER - 1
71-7291 - TSS EX PIPE CLAMP - 10

71-7318

70-9246

T120/40 TIMING COVER

 71-7318 timing cover

100
71-7345 - TSS BOTTOM COLLAR -

2

71-7346

-

TSS INLET VALVE GUIDE


12

71-7347

-

TSS EXHAUST VALVE GUIDE

 -

12

71-7350

-

TSS ROCKER SPINDLE





71-7353

-

TSS CRANK SLUDGE TUBE

 -

12

71-7354

-

TSS CRANK PLUG

 -

10
71-7357 - TSS TAPPET BLOCK BOLT - 2
71-7364 - TSS CRANKCASE TO HEAD STUD   7

71-7367

-

TSS VALVE COLLET

 -

2.75
71-7385A - TSS ALLOY PUSHROD TUBES PR

56

71-7400

-

PILLAR BOLT E/S

 -

3

71-7445

99-7570

TSS B/E SHELLS STD (EACH)

71-7451

-

TSS CYL HEAD GASKET

 -

10

-

71-7465

71-7003

T140 PRIMARY CH/CASE LATE


108

71-7472

-

TSS INLET ROCKER COVER

 -

32

71-7474

-

TSS EXH. ROCKER COVER


32

71-7489

-

OVER SIZE IDLER SPINDLE

 -

9
71-7500 - T140ES TIMING COVER

71-7507/8

-

T140E EX PIPES PUSH-OVER

 PR

110

71-7507/8UN

-

UNBALANCED  T140E  EX PIPES

 PR

100
71-7527 - TSX AIR INTAKE HOSE tsx

3
71-7528 - TSX BING MANIFOLD -

6

71-7555

71-3556

TR6/7 INLET MANIFOLD

 -

52
71-7563 - TR65 CYLINDER BARRELS - 245

71-7584

-

LATE T140 SUMP PLATE


18
71-7619 - ES GEAR LATE 717619D.JPG (14079 bytes)

75
71-7621 - ES GEAR,MESHES WITH 71-7619 717621.JPG (14373 bytes)

50
71-7628 - Bush intermediate T140 ES - 6

71-7634

-

TSS CYL BASE GASKET

 -

3

71-7690

-

TSS ROCKER EXHAUST LEFT

 -

32

71-7691

-

TSS ROCKER EXHAUST RIGHT


32

71-7692

-

TSS ROCKER INLET LEFT


32

71-7693

-

TSS ROCKER INLET RIGHT

 -

32
71-7709 - T140ES Intermediate spindle Mk111 - 40
71-7718 - TSS EX BRACKET -

6
82-0839 - 3/8 CEI STUD -

2.50
82-0879 - 1/4 CEI NUT - 0.75
82-0929 - BOLT 5/16 CEI by 1/2" -

3

82-0966

-

PRE-UNIT PETROL TK BOLT


2.50

82-0967

-

TANK MOUNTING RUBBER


1.25
82-0969 M RIGID CHAIN ADJ BOLT 82-0969.JPG (6080 bytes)

82-0976   spring washer rigid rear stand - 1.65
82-0991 - STUD RIGID FOOTREST BAR 1/2 CEI 12-1/4" LONG 82-0991.JPG (5460 bytes)

5.25

82-0977

-

REAR STAND BOLT

 -

2.50

82-1335

-

LOWER DISTANCE WASHER 650 UNIT



82-1369

-

BATT CARRIER ATT.SCREW 1/4 CEI -3/8

82-1561

-

SEAT LUG STUD 3/8" x26CEI

82-1605

-

T20/PRE/UNIT KNEE GRIP RH

82-1606

-

T20/PRE/UNIT KNEE GRIP LH

82-1680

-

STUD ENG TO FRAME

82-1695

-

PILLION F/R RUBBER TRI

 -

2.75

82-1711

-

P/U BOTTOM ENG/STUD 36-51 3/8 CEI

 -

2.50

82-1713

40-8331

OIL TANK FILTER WASHER

 -

1.25
82-1717 - T100 LATE PETROL TAP PUSHPULL/RES

82-1747

-

WHEEL NUT PRE-UNIT ¾ CEI

 wheel nut

 4
82-1747S - STAINLESS rear 3/4 CEI - 7.25

82-1808

-

PRE-UNIT PETROL TK BOLT


3.50

82-1814

-

K/START RUBBER

 -

2.15

82-1823

EARLY P/U TANK BADGE

 PR

12.50
82-1824 M CHAIN ADJ LOCK NUT RIGID 82-1824.JPG (8588 bytes)

82-1880

-

COPPER WASHER 5/16"

 -

0.60

82-1953

-

TANK KNEE PAD SCREW


3.25

82-2184

71-2598

 THICK WASHER,STAND & HEAD BOLT ⅜

 -

0.60

82-2335

-

BOLT SADDLE MTG BRACKET

 -

1.15

82-2414

-

STUD ENG TO FRAME

82-2551/2

-

PRE/UNIT KNEE GRIPS

82-2551-2

19

82-2610

40-4735

PROP STAND SPRING PRE-UNT


4

82-2725

-

NUT CENTRE STAND ½"

 -

1.30
82-2825 - 3TA STUD -

1.50

82-2842

-

STUD SEAT MTG REAR FRAME ⅜ CEI × 4"

 -

3

82-2933

-

3-BAR P/U TANK GRID

82-2936S

-

TANK GRID SCREW

 -

3.50

82-3069

-

HEAD STEADY SPACER

 -

1.50

82-3096

40-4734

LOCK TAB WASHER

 82-3096

2

82-3097

40-4733

SIDE STAND BOLT up to 1966


3

82-3108

-

BOLT ⅜"x 7" 26 Tpi

 -

6
82-3113 - TANK BADGE SCREW PRE 1959


82-3179 W26419 OIL TANK FILTER 82-3179.JPG (4093 bytes)

22
82-3179S STAINLESS Oiltankfilter.JPG (16154 bytes)

30

82-3182S

-

OIL PIPE UNION NUT 21/54"

 -

3.15
82-3184 - CUPPED WASHER 82-3184.JPG (3832 bytes)

1.50

82-3216

W72031

OIL TK FILL CAP NON VENT

 -

16

82-3216V

W72029

OIL TK FILL CAP VENTED

 -

16

82-3220

-

FUEL TANK CAP FLAT TOP

82-3220

FUEL TANK CAP

 -

16

82-3248

-

BOLT FR/S-C CONNECT ⅜

82-3334

-

PETROL PIPE STUB STRAIGHT

 82-3334 Petrol pipe.JPG (9630 bytes)

3

82-3335

-

PETROL PIPE STUB 90 DEG

 fuel pipe 90

2.50

82-3337

-

PETROL PIPE NUT


2

82-3353

-

PETROL PIPE STUB OBTUSE

 fuel pipe obtuse

2.50
82-3564 - S/ARM PIN PRE-UNIT 82-3564.JPG (6443 bytes)

24

82-3575

-

PRE-UNIT G/BOX PIVOT BOLT 7/16 CEI

 -

9

82-3592

-

STUD FOOTREST FRONT PREUNIT 1/2 CEI by 11 1/4

 -

5

82-3597

-

 BRAKE ROD CEI

 -

11

82-3617

-

CTR STAND SPRING T100/110


5
82-3618 PREUNIT CENTRE ST SPRING PLATE -

6.50

82-3619

-

CTR STAND BOLT PRE-UNIT

 82-3619

5

82-3655

-

OIL PIPE/TANK SPIGOT 500/650

 -

3

82-3665

-

3/5TA REAR ENG PLATE STUD

 -

2

82-3667

-

BRAKE ROD REAR ADJUSTER CEI

 -

4.50

82-3690

-

PRE-UNIT S/ARM BUSH

 -

7.50

82-3723L

-

PRE 1967  PROP STAND LONG 19" WHEEL


82-3723S   18" WHEEL - 37


82-3771

-

FLANGED CEI NUT ASSY


5
82-3772 - NUT GEARBOX TOP STUD -

4

82-3798

-

P/UNIT S/ARM SPINDLE CAP

 -

2

82-3799

-

T100 S/ARM E/CAP RET NUT

82-3780 - BOLT 7/16 CEI FRAME -

3

82-3805

-

SILENCER BOLT 5/16" CEI by 1 ⅝

1.50

82-3803

-

'P' CLIP

 p clip.JPG (10087 bytes)

2.50
82-3805 - BOLT 82-3805.JPG (4415 bytes)

82-3814

-

CUPPED WASHER PETROL TANK


1.50
82-3859 M AIR HOSE CLIP 82-3859.JPG (9422 bytes)

1.75

82-3875

-

TOOL BOX SCREW PRE-UNIT

 -

3.50

82-3917

-

TANK GRID 60 ONWARDS



82-4047

-

OIL TANK CAP SEALING WASHER

 -

1.25

82-4048

-

PETROL TANK CAP SEAL

 -

1.25

82-4076

-

unit 350/500 S/ARM SPINDLE BUSH

 -

5

82-4078

-

SWINGING ARM SPACING WASH

82-4087 - 7/16 CEI BOLT BY 1 ½

82-4127/8

-

TANK BADGE 3TA/5TA & PREUNIT 3 GALL


53

82-4129

C274D

SIDE PANEL BADGE SCREW 2BA

 -

1.25

82-4134

-

T100 CH/GUARD FR/MOUNT

82.4135

-

UPPER REAR CH/GUARD SWIVEL BOLT

 -

2

82-4146

00-0150

SEE PAGE TRI 1

82-4148

00-0150

82-4149

00-0150

82-4151

00-0150

82-4195

W26094

3TA S/ARM PIN

 82-4195

28

82-4196

-

T100 S/ARM SPIN. END CAP


2.50

82-4215

-

FOOTREST RH FRONT

 -

82-4222

-

SEAT HINGE EARLY


7.50
      -


82-4226 - SEAT PLUNGER SEAT KNOB 6
82-4227 - CHROME KNOB CHROME KNOB 6
  RS001 SEAT CATCH PLUNGER ASS CHROME - 12.50

82-4228

-

SEAT CATCH SPRING

 -

1.50
82-4229   LH Rear engine plate unit 500 - 9
82-4230   RH - 10

82-4235

-

SEE PAGE TRI 1-

82-4236

-

SEE PAGE TRI 1

82-4237

-

82-4238

-

82-4249

-

BATHTUB  PANEL BEADING 20"

 -

6.50

82-4299

-

MUDGUARD FIXING WASHER 1/4 LARGE OD

82.4309

-

STUD FOOTREST HANGER

  -

82-4312 - Twenty one diecast sript fits on side of bathtubs -
82-4316 - 82-4316.JPG (7341 bytes)

3
82-4317 - SPIRE NUT FOR SIDE PANEL SCRIPT -

0.75

82-4323

-

SEE PAGE TR 1

82-4324

-

SEE PAGE TRI 1

82-4369 - 650 FRAME BOLT 7/16 CEI -

4
82-4388 - PRE 1967 SIDE STAND 17" WHEEL 3TA 3TAstand 37
82-4398 - Tank strip 500 1957-64 - 39

82-4484

-

CENTRE STAND BOLT TAB WASHER


1.00
82-4523 R SPEEDTWIN PANEL SCRIPT speedtwin

24
82-4524 R T100 SCRIPT -

24
82-4585 - Brake rod adjuster CEI

82-4657 R TANK RUBBER STRIP DUPLEX 650 -

7.50
82-4663 R THUNDERBIRD MOTIF Thunderbird 24

82-4665

-

SEE PAGE TRI 1

82-4667

-

SEE PAGE TRI 1

82-4670 - CENTRE STAND SPRING LINK 1960/62 DUPLEX 650 82-4670.JPG (10378 bytes)

6.75

82-4671

-

CTR STAND SPRING TRIDENT


5

82-4672

W61044

6T AIR HOSE 1960-62

82-4681 - PRE-UNIT GEARBOX STUD 7/16CEI

82-4682

-

STUD 3/8" CEI 7 23/32

 -

2
82-4699 - TANK STRAP 4GALL 1060-62 DUPLEX

82-4712

-

PRE-UNIT PROP STAND SHORT

82-4717

-

NUT 2 BA

 -

0.35
82-4766/7 - 4 GALL TANK BADGES 650 1960 TO 1965(pair) 4 gallon tank badge

85
82-4770 - TANK RUBBER 1960/62 650 - 4
82-4810 048 PANCAKE BAND CLIP -

82-4898

BB010

SEAT RUBBER/BUFFER


2
82-5087 - FOOTREST PLATE UNIT 500 - 13
82-5088 FOOTREST PLATE 500 -

13

82-5153

W61054

T100 CENTRE STAND PRE 1966

 -

64

82-5228

-

TANK RUBBER PRE-0.I.F.

 -

1.50

82-5229

-

TANK MTG RUBBER


1.50

82-5313

-

S-ARM BOBBIN DISTANCE PC 650 UNIT

 -

6

82-5336

-

TANK MTG RUBBER

 -

1.25

82-5337

-

REAR TK MTG BOLT PRE 68 CEI

 -

2.50

82-5343

-

OIL TANK DRAIN PLUG

 -

2
82-5372 R TIGER90 SIDE PANEL SCRIPT T90

24

82-5394

-

TR6/120 S/PANEL 2SWITCH B

82-5398 - TANK STRIP 650 4GALL 63-68 82-5398.JPG (10345 bytes)

39

82-5401/2

W27403

TANK KNEE GRIPS


12.50
82-5411 - 7/16 CEI BOLT

82-5412   Brake light sw clip to rod
82-5413 - washer brake light switch   2

82-5424

-

LIFTING HANDLE 62-66

82-5529

-

3/5TA CENTRE STAND EARLY



82-5531 - 650 UNIT FRAME BOLT BOTTOM 7/16 CEI -
82-5532 - 650 UNIT BOTTOM SPACER -

1
82-5536 - CHAIN GUARD GROMMET -

2.50
82-5564 - Tank strip 650 export 1963-68 - 39

82-5559X

-

T90/100 S/PANEL 63/65 U/P

82-5604S   REAR BRAKE LEVER PIVOT 650 1963-64 - 20
82-5605 - BOLT 7/16 CEI REAR SUB FRAME 82-5605.JPG (4289 bytes)


82-5564 - 650 TANK STRIP 1963-68 US -

30

82-5678

-

CENTRE STAND BOLT


4

82-5679

-

CENTRE STAND BOLT WASHER

 -

0.65

82-5753

-

GROMMET KNEESHIELDS


0.65
82-5910 - RH RIDERS FOOTREST TRIDENT 82-5910.jpg (22774 bytes)

82-5924

-

T20/120 REAR NUMBER/PLATE BRACKET 1955-66

 -

22

82-5932



T120 CTR STAND 1964-69

 -

86

82-5939

-

SIDE PANEL FIXING BRACKET 1963-67

82-5943

-

FOOTREST DOWEL STEEL

 -

1

82-5944

-

S/ARM SPINDLE TAB WASHER

 -

1.25
82-5958   389 carb adaptor ring for pancake filter 389 carb ring 4

82-5994

-

REAR M/GUARD CLIP


4


powered by FreeFind
TRIUMPH Parts 7 Electrical Parts 8
Pipes/silencers/bars/levers Parts 9 Carbs,books,tools Parts10 LINKS PAGE         ORDERING goodS Ordering

                                                           0776-555-3258

TRIUMPH PARTS PAGE
